This page intends to collect information about how we map the SModelS description of events onto the Tx nomenclature. The list has been created from the database version 1.2.2, considering also superseded results.

There is also a ListOfAnalyses, a ListOfAnalysesWithSuperseded, and Validation.

# Tx Topology Graph Appears in
1 T1
[[[q,q]],[[q,q]]]
(MET,MET)
T1 many (17)
2 T1bbbb
[[[b,b]],[[b,b]]]
(MET,MET)
T1bbbb many (24)
3 T1bbbt
[[[b,b]],[[b,t]]]
(MET,MET)
T1bbbt ATLAS-CONF-2013-024
ATLAS-CONF-2013-037
ATLAS-CONF-2013-047
ATLAS-CONF-2013-053
ATLAS-CONF-2013-054
ATLAS-CONF-2013-061
ATLAS-CONF-2013-062
ATLAS-CONF-2013-093
4 T1bbqq
[[[b,b]],[[q,q]]]
(MET,MET)
T1bbqq ATLAS-CONF-2013-024
ATLAS-CONF-2013-047
ATLAS-CONF-2013-053
ATLAS-CONF-2013-054
ATLAS-CONF-2013-061
ATLAS-CONF-2013-062
5 T1bbtt
[[[b,b]],[[t+,t-]]]
(MET,MET)
T1bbtt ATLAS-CONF-2013-024
ATLAS-CONF-2013-037
ATLAS-CONF-2013-047
ATLAS-CONF-2013-048
ATLAS-CONF-2013-053
ATLAS-CONF-2013-054
ATLAS-CONF-2013-061
ATLAS-CONF-2013-062
6 T1btbt
[[[b,t]],[[b,t]]]
(MET,MET);
[[[t+,b]],[[t+,b]]]+
[[[t-,b]],[[t-,b]]]
(MET,MET);
[[[t,b]],[[t,b]]]
(MET,MET)
T1btbt many (11)
7 T1btqq
[[[b,t]],[[q,q]]]
(MET,MET)
T1btqq ATLAS-CONF-2013-024
ATLAS-CONF-2013-037
ATLAS-CONF-2013-047
ATLAS-CONF-2013-053
ATLAS-CONF-2013-054
ATLAS-CONF-2013-061
ATLAS-CONF-2013-062
8 T1bttt
[[[b,t]],[[t+,t-]]]
(MET,MET)
T1bttt ATLAS-CONF-2013-024
ATLAS-CONF-2013-037
ATLAS-CONF-2013-047
ATLAS-CONF-2013-048
ATLAS-CONF-2013-054
ATLAS-CONF-2013-061
ATLAS-CONF-2013-062
9 T1qqtt
[[[q,q]],[[t+,t-]]]
(MET,MET)
T1qqtt ATLAS-CONF-2013-024
ATLAS-CONF-2013-037
ATLAS-CONF-2013-047
ATLAS-CONF-2013-048
ATLAS-CONF-2013-054
ATLAS-CONF-2013-061
ATLAS-CONF-2013-062
10 T1ttofftt
[[[t,b,W]],[[t,b,W]]]
(MET,MET)
T1ttofftt ATLAS-SUSY-2016-14
11 T1tttt
[[[t+,t-]],[[t+,t-]]]
(MET,MET);
[[[t,t]],[[t,t]]]
(MET,MET);
[[[t+,t-]],[[t-,t+]]]
(MET,MET)
T1tttt many (48)
12 T1ttttoff
[[[b,b,W,W]],[[b,b,W,W]]]
(MET,MET);
[[[b,W,b,W]],[[b,W,b,W]]]
(MET,MET)
T1ttttoff many (29)
13 T2
[[[q]],[[q]]]
(MET,MET)
T2 many (13)
14 T2bb
[[[b]],[[b]]]
(MET,MET)
T2bb many (20)
15 T2bbWW
[[[b,W]],[[b,W]]]
(MET,MET);
[[[b,W+]],[[b,W-]]]
(MET,MET)
T2bbWW ATLAS-CONF-2013-048
ATLAS-SUSY-2013-19
ATLAS-SUSY-2013-21
CMS-SUS-14-021
16 T2bbWWoff
[[[b,L,nu]],[[b,L,nu]]]+
[[[b,q,q]],[[b,q,q]]]+
[[[b,q,q]],[[b,L,nu]]]
(MET,MET);
[[[b,l,nu]],[[b,q,q]]]
(MET,MET);
[[[b,l,nu]],[[b,l,nu]]]
(MET,MET)
T2bbWWoff ATLAS-SUSY-2016-17
CMS-PAS-SUS-16-052
ATLAS-SUSY-2013-21
CMS-SUS-14-021
17 T2bt
[[[b]],[[t]]]
(MET,MET)
T2bt ATLAS-CONF-2013-024
ATLAS-CONF-2013-037
ATLAS-CONF-2013-047
ATLAS-CONF-2013-053
ATLAS-CONF-2013-054
ATLAS-CONF-2013-061
ATLAS-CONF-2013-062
ATLAS-CONF-2013-093
18 T2cc
[[[c]],[[c]]]
(MET,MET);
[[[q]],[[q]]]
(MET,MET)
T2cc ATLAS-SUSY-2016-26
CMS-SUS-16-032
CMS-SUS-16-036
CMS-SUS-16-049
ATLAS-SUSY-2013-21
19 T2tt
[[[t]],[[t]]]
(MET,MET);
[[[t+]],[[t-]]]
(MET,MET)
T2tt many (39)
20 T2ttC
[[[b,q,q]],[[b,q,q]]]
(MET,MET)
T2ttC CMS-SUS-16-049
21 T2ttoff
[[[b,W]],[[b,W]]]
(MET,MET);
[[[W,b]],[[W,b]]]
(MET,MET)
T2ttoff many (19)
22 T3GQ
[[[q]],[[q],[q]]]
(MET,MET)
T3GQ ATLAS-SUSY-2013-02
CMS-SUS-13-012
23 T4bnutau-
bnutau

[[[b,nu],[ta]],[[b,nu],[ta]]]
(MET,MET)
T4bnutaubnutau ATLAS-SUSY-2016-19
24 T5
[[[q],[q]],[[q],[q]]]
(MET,MET)
T5 ATLAS-SUSY-2013-02
ATLAS-SUSY-2013-04
CMS-SUS-13-012
25 T5WW
[[[q,q],[W]],[[q,q],[W]]]
(MET,MET);
[[[q,q],[W+]],[[q,q],[W+]]]+
[[[q,q],[W-]],[[q,q],[W-]]]
(MET,MET)
T5WW CMS-SUS-16-035
CMS-SUS-16-042
ATLAS-CONF-2013-047
ATLAS-SUSY-2013-02
ATLAS-SUSY-2013-04
CMS-SUS-13-012
26 T5WWoff
[[[q,q],[q,q]],[[q,q],[q,q]]]
(MET,MET);
[[[q,q],[l+,nu]],[[q,q],[l+,nu]]]+
[[[q,q],[l-,nu]],[[q,q],[l-,nu]]]
(MET,MET);
[[[q,q],[q,q]],[[q,q],[q,q]]]
(MET,MET);
[[[q,q],[l,nu]],[[q,q],[q,q]]]
(MET,MET)
T5WWoff CMS-SUS-16-035
CMS-SUS-16-042
ATLAS-CONF-2013-047
ATLAS-SUSY-2013-02
ATLAS-SUSY-2013-04
CMS-SUS-13-012
27 T5ZZ
[[[q,q],[Z]],[[q,q],[Z]]]
(MET,MET)
T5ZZ ATLAS-SUSY-2016-33
CMS-SUS-16-034
ATLAS-SUSY-2013-04
CMS-SUS-13-012
28 T5bbbb
[[[b],[b]],[[b],[b]]]
(MET,MET)
T5bbbb ATLAS-CONF-2013-024
ATLAS-CONF-2013-037
ATLAS-CONF-2013-047
ATLAS-CONF-2013-053
ATLAS-CONF-2013-054
ATLAS-CONF-2013-061
ATLAS-CONF-2013-062
CMS-SUS-13-012
29 T5bbbt
[[[b],[b]],[[b],[t]]]
(MET,MET)
T5bbbt ATLAS-CONF-2013-024
ATLAS-CONF-2013-037
ATLAS-CONF-2013-047
ATLAS-CONF-2013-053
ATLAS-CONF-2013-054
ATLAS-CONF-2013-061
ATLAS-CONF-2013-062
ATLAS-CONF-2013-093
30 T5btbt
[[[b],[t]],[[b],[t]]]
(MET,MET)
T5btbt ATLAS-CONF-2013-024
ATLAS-CONF-2013-037
ATLAS-CONF-2013-047
ATLAS-CONF-2013-048
ATLAS-CONF-2013-053
ATLAS-CONF-2013-054
ATLAS-CONF-2013-061
ATLAS-CONF-2013-062
ATLAS-CONF-2013-093
31 T5gg
[[[q,q],[y]],[[q,q],[y]]]
(MET,MET)
T5gg CMS-SUS-16-046
CMS-SUS-16-047
32 T5tbtb
[[[t],[b]],[[t],[b]]]
(MET,MET)
T5tbtb ATLAS-CONF-2013-024
ATLAS-CONF-2013-037
ATLAS-CONF-2013-047
ATLAS-CONF-2013-048
ATLAS-CONF-2013-053
ATLAS-CONF-2013-054
ATLAS-CONF-2013-061
ATLAS-CONF-2013-062
ATLAS-CONF-2013-093
33 T5tbtt
[[[t],[b]],[[t+],[t-]]]+
[[[t],[b]],[[t-],[t+]]]
(MET,MET)
T5tbtt ATLAS-CONF-2013-024
ATLAS-CONF-2013-037
ATLAS-CONF-2013-047
ATLAS-CONF-2013-048
ATLAS-CONF-2013-053
ATLAS-CONF-2013-054
ATLAS-CONF-2013-061
ATLAS-CONF-2013-062
34 T5tctc
[[[t],[q]],[[t],[q]]]
(MET,MET)
T5tctc CMS-SUS-16-035
CMS-SUS-16-050
ATLAS-CONF-2013-047
ATLAS-SUSY-2013-02
35 T5ttbbWW-
off

[[[t,b],[q,q]],[[t,b],[q,q]]]
(MET,MET)
T5ttbbWWoff CMS-SUS-16-035
36 T5ttofftt
[[[b,W],[t]],[[b,W],[t]]]
(MET,MET)
T5ttofftt CMS-SUS-16-037
37 T5tttt
[[[t],[t]],[[t],[t]]]
(MET,MET);
[[[t+],[t-]],[[t-],[t+]]]+
[[[t-],[t+]],[[t-],[t+]]]+
[[[t+],[t-]],[[t+],[t-]]]
(MET,MET);
[[[t+],[t-]],[[t+],[t-]]]+
[[[t-],[t+]],[[t-],[t+]]]
(MET,MET)
T5tttt many (14)
38 T6HHtt
[[[h],[t]],[[h],[t]]]
(MET,MET)
T6HHtt CMS-SUS-16-041
39 T6WW
[[[q],[W]],[[q],[W]]]
(MET,MET)
T6WW ATLAS-CONF-2013-089
ATLAS-SUSY-2013-02
40 T6ZZ
[[[q],[Z]],[[q],[Z]]]
(MET,MET)
T6ZZ ATLAS-SUSY-2016-33
41 T6ZZofftt
[[[l+,l-],[t]],[[l+,l-],[t]]]
(MET,MET)
T6ZZofftt CMS-SUS-16-041
42 T6ZZtt
[[[Z],[t]],[[Z],[t]]]
(MET,MET)
T6ZZtt CMS-SUS-16-041
ATLAS-CONF-2013-025
ATLAS-SUSY-2013-08
43 T6bbHH
[[[b],[h]],[[b],[h]]]
(MET,MET)
T6bbHH CMS-SUS-16-045
44 T6bbWW
[[[b],[W]],[[b],[W]]]
(MET,MET);
[[[b],[W+]],[[b],[W-]]]
(MET,MET)
T6bbWW many (11)
45 T6bbWWoff
[[[b],[l,nu]],[[b],[q,q]]]
(MET,MET);
[[[b],[mu,nu]],[[b],[q,q]]]+
[[[b],[e,nu]],[[b],[q,q]]]
(MET,MET);
[[[b],[L,nu]],[[b],[L,nu]]]+
[[[b],[L,nu]],[[b],[q,q]]]+
[[[b],[q,q]],[[b],[q,q]]]
(MET,MET);
[[[b],[L-,nu]],[[b],[L+,nu]]]
(MET,MET);
[[[b],[L,nu]],[[b],[q,q]]]
(MET,MET);
[[[b],[q,q]],[[b],[q,q]]]
(MET,MET)
T6bbWWoff CMS-PAS-SUS-16-052
CMS-SUS-16-049
ATLAS-CONF-2013-001
ATLAS-CONF-2013-048
ATLAS-SUSY-2013-05
CMS-PAS-SUS-13-023
CMS-SUS-13-011
CMS-SUS-13-012
46 T6gg
[[[q],[y]],[[q],[y]]]
(MET,MET)
T6gg CMS-SUS-16-046
CMS-SUS-16-047
47 T6ttWW
[[[t],[W]],[[t],[W]]]
(MET,MET);
[[[t+],[W-]],[[t-],[W+]]]
(MET,MET)
T6ttWW ATLAS-SUSY-2016-14
CMS-SUS-16-035
CMS-SUS-16-041
ATLAS-CONF-2013-007
CMS-SUS-13-013
48 T6ttWWoff
[[[t],[l,nu]],[[t],[l,nu]]]
(MET,MET);
[[[t+],[l-,nu]],[[t-],[q,q]]]+
[[[t-],[l+,nu]],[[t+],[q,q]]]
(MET,MET);
[[[t],[L,nu]],[[t],[q,q]]]
(MET,MET);
[[[t],[q,q]],[[t],[q,q]]]
(MET,MET)
T6ttWWoff CMS-SUS-16-035
CMS-SUS-16-041
ATLAS-CONF-2013-007
CMS-SUS-13-013
49 T6ttoffWW
[[[b,W],[W]],[[b,W],[W]]]
(MET,MET)
T6ttoffWW CMS-SUS-16-035
CMS-SUS-16-041
50 TChiChipm-
SlepL

[[[L+],[L-]],[[L],[nu]]]+
[[[L+],[L-]],[[nu],[L]]]+
[[[L-],[L+]],[[L],[nu]]]+
[[[L-],[L+]],[[nu],[L]]]
(MET,MET);
[[[e+],[e-]],[[L],[nu]]]+
[[[e+],[e-]],[[nu],[L]]]+
[[[e-],[e+]],[[L],[nu]]]+
[[[e-],[e+]],[[nu],[L]]]+
[[[mu+],[mu-]],[[L],[nu]]]+
[[[mu+],[mu-]],[[nu],[L]]]+
[[[mu-],[mu+]],[[L],[nu]]]+
[[[mu-],[mu+]],[[nu],[L]]]+
[[[ta+],[ta-]],[[L],[nu]]]+
[[[ta+],[ta-]],[[nu],[L]]]+
[[[ta-],[ta+]],[[L],[nu]]]+
[[[ta-],[ta+]],[[nu],[L]]]
(MET,MET);
[[[L],[L]],[[L],[nu]]]+
[[[L],[L]],[[nu],[L]]]
(MET,MET)
TChiChipmSlepL CMS-SUS-16-039
ATLAS-CONF-2013-035
ATLAS-SUSY-2013-12
CMS-PAS-SUS-12-022
CMS-SUS-13-006
51 TChiChipm-
SlepStau

[[[L],[L]],[[nu],[ta]]]
(MET,MET)
TChiChipmSlepStau CMS-SUS-16-039
CMS-PAS-SUS-12-022
CMS-SUS-13-006
52 TChiChipm-
StauL

[[[nu],[ta]],[[ta+],[ta-]]]+
[[[ta],[nu]],[[ta+],[ta-]]]+
[[[nu],[ta]],[[ta-],[ta+]]]+
[[[ta],[nu]],[[ta-],[ta+]]]
(MET,MET)
TChiChipmStauL ATLAS-SUSY-2013-12
53 TChiChipm-
StauStau

[[[ta],[ta]],[[nu],[ta]]]
(MET,MET);
[[[ta+],[ta-]],[[nu],[ta]]]+
[[[ta-],[ta+]],[[nu],[ta]]]
(MET,MET)
TChiChipmStauStau CMS-SUS-16-039
CMS-PAS-SUS-12-022
54 TChiWH
[[[W]],[[h]]]
(MET,MET);
[[[h]],[[W]]]
(MET,MET)
TChiWH CMS-PAS-SUS-17-004
CMS-SUS-16-039
CMS-SUS-16-043
CMS-SUS-16-045
ATLAS-CONF-2013-093
ATLAS-SUSY-2013-12
ATLAS-SUSY-2013-23
CMS-SUS-13-006
55 TChiWW
[[[W]],[[W]]]
(MET,MET);
[[[W+]],[[W-]]]
(MET,MET)
TChiWW ATLAS-SUSY-2013-11
CMS-SUS-13-012
56 TChiWWoff
[[[l+,nu]],[[l-,nu]]]
(MET,MET)
TChiWWoff ATLAS-SUSY-2013-11
57 TChiWZ
[[[W]],[[Z]]]
(MET,MET)
TChiWZ many (10)
58 TChiWZoff
[[[mu+,mu-]],[[l,nu]]]+
[[[e+,e-]],[[l,nu]]]
(MET,MET);
[[[L,nu]],[[e+,e-]]]+
[[[L,nu]],[[mu+,mu-]]]+
[[[L,nu]],[[ta+,ta-]]]
(MET,MET)
TChiWZoff CMS-PAS-SUS-17-004
CMS-SUS-16-039
ATLAS-CONF-2013-035
ATLAS-SUSY-2013-12
CMS-SUS-13-006
59 TChiZZ
[[[Z]],[[Z]]]
(MET,MET)
TChiZZ CMS-SUS-13-012
60 TChipChim-
SlepSnu

[[[L-],[nu]],[[nu],[L+]]]+
[[[L+],[nu]],[[nu],[L-]]]+
[[[L+],[nu]],[[L-],[nu]]]+
[[[nu],[L+]],[[nu],[L-]]]
(MET,MET)
TChipChimSlepSnu ATLAS-SUSY-2013-11
CMS-PAS-SUS-12-022
61 TGQ
[[[q]],[[q,q]]]
(MET,MET)
TGQ ATLAS-CONF-2013-047
ATLAS-CONF-2013-054
62 TGQbbq
[[[b,b]],[[q]]]
(MET,MET)
TGQbbq ATLAS-CONF-2013-024
ATLAS-CONF-2013-047
ATLAS-CONF-2013-053
ATLAS-CONF-2013-054
ATLAS-CONF-2013-061
ATLAS-CONF-2013-062
63 TGQbtq
[[[b,t]],[[q]]]
(MET,MET)
TGQbtq ATLAS-CONF-2013-024
ATLAS-CONF-2013-037
ATLAS-CONF-2013-047
ATLAS-CONF-2013-053
ATLAS-CONF-2013-054
ATLAS-CONF-2013-061
ATLAS-CONF-2013-062
64 TGQqtt
[[[q]],[[t+,t-]]]
(MET,MET)
TGQqtt ATLAS-CONF-2013-024
ATLAS-CONF-2013-037
ATLAS-CONF-2013-047
ATLAS-CONF-2013-048
ATLAS-CONF-2013-053
ATLAS-CONF-2013-054
ATLAS-CONF-2013-061
ATLAS-CONF-2013-062
65 THSCPM1b
[[],[]]
(HSCP,HSCP)
THSCPM1b CMS-PAS-EXO-16-036
CMS-EXO-12-026
CMS-EXO-13-006
66 THSCPM2b
[[*],[]]
(MET,HSCP)
THSCPM2b CMS-PAS-EXO-16-036
CMS-EXO-13-006
67 THSCPM3
[[[*]],[[*]]]
(HSCP,HSCP)
THSCPM3 CMS-PAS-EXO-16-036
CMS-EXO-13-006
68 THSCPM4
[[*],[[*]]]
(MET,HSCP)
THSCPM4 CMS-PAS-EXO-16-036
CMS-EXO-13-006
69 THSCPM5
[[[*],[*]],[[*],[*]]]
(HSCP,HSCP)
THSCPM5 CMS-PAS-EXO-16-036
CMS-EXO-13-006
70 THSCPM6
[[*],[[*],[*]]]
(MET,HSCP)
THSCPM6 CMS-PAS-EXO-16-036
CMS-EXO-13-006
71 THSCPM7
[[[*]],[[*],[*]]]
(HSCP,HSCP)
THSCPM7 CMS-PAS-EXO-16-036
CMS-EXO-13-006
72 THSCPM8
[[[*,*]],[[*,*]]]
(HSCP,HSCP)
THSCPM8 CMS-PAS-EXO-16-036
CMS-EXO-13-006
73 TRHadGM1
[[],[]]
(RHadronG,RHadronG)
TRHadGM1 CMS-PAS-EXO-16-036
CMS-EXO-12-026
74 TRHadQM1
[[],[]]
(RHadronQ,RHadronQ)
TRHadQM1 CMS-PAS-EXO-16-036
CMS-EXO-12-026
75 TScharm
[[[c]],[[c]]]
(MET,MET)
TScharm ATLAS-SUSY-2014-03
76 TSlepSlep
[[[e+]],[[e-]]]+
[[[mu+]],[[mu-]]]
(MET,MET)
TSlepSlep ATLAS-CONF-2013-049
ATLAS-SUSY-2013-11
CMS-PAS-SUS-12-022
CMS-SUS-13-006
